PIUSI PUMP 240V AC 56lpm Panther EX56 · F00580030
Regular price $1,276.00
PIUSI PUMP 240V AC 56lpm Panther EX56 · F00580030
ATEX Zone 1 cast-iron transfer pump. 56 lpm at 240V AC, continuous duty, feet-mounted. Suits petrol, diesel, kerosene in hazardous-area installations.
Key Features
- ATEX II 2 G Ex d IIA T4 Gb explosion-proof rating for Zone 1 hazardous areas
- 56 l/min continuous duty at 240V AC, 500W single-phase motor
- Cast-iron pump body with sintered-steel rotor and Viton seals
- Magnetic ON/OFF switch and integrated bypass valve
- 1" BSP inlet and outlet for standard fuel-line plumbing
- Suitable for diesel, petrol, and kerosene
- Removable feet for permanent bolt-down installation
- 12-month Piusi manufacturer warranty plus ATEX/IECEx certificate
Technical Specifications
| Manufacturer Code | F00580030 |
| Model | Panther EX 56 (Feet) |
| Pump Type | Self-priming vane with bypass |
| Flow Rate | 56 l/min (14.7 GPM) |
| Voltage | 230V / 50Hz (compatible 240V AU) |
| Power | 500 W |
| Max Current | 2.3 A |
| RPM | 2800 |
| ATEX Marking | II 2 G Ex d IIA T4 Gb |
| Duty Cycle | Continuous (S1) |
| Inlet Thread | 1" BSP |
| Outlet Thread | 1" BSP |
| Switch | Magnetic ON/OFF |
| Body Material | Cast iron |
| Rotor | Sintered steel |
| Vanes | Technopolymer |
| Seal | Viton |
| Shaft | Steel |
| Mounting | Feet (removable, bolt-down) |
| Fluid Compatibility | Diesel, petrol, kerosene |
| Weight | 12.4 kg |
| Packaging | 400 x 240 x 300 mm |
| Country of Origin | Italy |
| Warranty | 12 months |
Frequently Asked Questions
What's the difference between the Panther 56 and the Panther EX 56?
The Panther 56 is rated for diesel only. The Panther EX 56 carries ATEX II 2 G certification for petrol, kerosene, and other flammable liquids in Zone 1 / Zone 2 hazardous areas. Same pump architecture, hardened for hazardous service.
Is this the feet or drum version?
Feet version (F00580030). Comes with removable mounting feet for bolt-down installation. The drum version (F00580010 in Piusi's catalogue) ships with a drum connector and nozzle holder for IBC / 200L drum mounting - speak to us if that's what you need.
Why ATEX for diesel?
Diesel itself is not flagged as Zone 1, but if you're sharing a yard, workshop, or storage area with petrol or other flammable hydrocarbons, your hazardous-area classification may require ATEX-certified equipment across the whole installation. Many WHS-conscious sites standardise on ATEX as a future-proofing measure.
Does it run continuously or have a duty cycle?
Continuous duty (S1). You can run it back-to-back for shift-long fills without thermal cut-out, unlike the Cube cabinet dispensers which have a 30-minute on/off cycle.
What flow meter pairs with it?
For ATEX-compliant metering, pair with the Piusi K600 ATEX or K33 ATEX mechanical meter. Non-ATEX meters cannot legally be used in the same Zone 1 installation.
Does it come with a nozzle and hose?
No - this is the pump-only version. Speak to us about matched ATEX-rated nozzles, hoses, and suction kits to build a complete petrol or diesel transfer station.
Shipping
- Weight: 12.4 kg
- Freight: Carton
- Ships from Brisbane in original Piusi packaging. 400 x 240 x 300 mm carton.
| DATA SHEET |
For technical enquiries, installation or commissioning support, contact CEA Petroleum at sales@ceapet.com.au or call 1300 733 102.
